Battery Type | Lithium Iron Phosphate |
Nominal Voltage | 12 V |
Nominal Capacity | 200 Ah |
Nominal Energy | 2.5 kWh |
Net Weight | 26.7 kg |
Dimensions | L 281 x W 181 x H 506 mm |
IP Level | 20 |
Parallel Operation | Up to 16 Units |
Warranty | 5 Years Replacement |
Cycle Life | 3500-Based On Real World Performance |
Model | PPSESSLFP12V2.5kWh |
Battery Type | Lithium Iron Phosphate |
Nominal Voltage | 12 V |
Nominal Capacity | 200 Ah |
Nominal Energy | 2.5 kWh |
Charge Voltage | 14.6 V |
Charge Current (Recomm.) | 100 A |
Net Weight | 26.7 kg |
Dimensions | L 281 x W 181 x H 506 mm |
Wireless Communication | Bluetooth |
Cell Configuration | 4s2p |
DOD | 90 % |
Charge Current (Max) | 100 A |
Discharge Current (Max) | 100 A |
Battery Level Indicator | SOC Display |
On Board Display | Yes |
Communication Ports | RS485 / RS232 / CAN |
On Board Circuit Breaker | Yes |
Operating Temperature-Charge | 0° to 45° |
Operating Temperature-Discharge | -20° to 60° |
Storage Temperature | 0° to 40° |
Humidity | 5 % to 95 % |
IP Level | 20 |
Parallel Operation | Up to 16 Units |
Warranty | 5 Years Replacement |
Replaceable Cartridge | Yes |
Cycle Life | 3500-Based On Real World Performance |
Yes, Power Pack batteries support parallel operation of up to 16 units, allowing you to scale your
energy storage capacity according to your requirements.
Power Pack batteries are covered under a 5 years replacement warranty from the date of purchase.
To claim the warranty, contact our customer service team at 0328-2013435 or info@powerpack.com.pk You'll need to provide the invoice and details about the issue. After evaluation, we will guide you on the next steps for replacement.
Yes, Power Pack batteries are equipped with advanced features like WiFi and Bluetooth
connectivity. Using the mobile app, you can monitor battery performance, state of charge (SOC),
and other metrics in real time.
Absolutely! Power Pack batteries are versatile and suitable for residential, commercial and
industrial purposes.
Yes, we offer comprehensive after-sales services, including installation support, troubleshooting,
and maintenance. Our remote team is also available to guide you through technical issues.
FEATURES
Longer Lifespan – Up to 5x longer cycle life compared to lead-acid batteries
Lightweight & Compact – Higher energy density with reduced weight and size
Smart BMS Protection – Prevents overcharging, overheating, and short circuits
Bluetooth Connectivity – Easily monitor battery status via mobile devices
Parallel Operation Support – Expandable up to 40kWh for increased power capacity
Backup Power – Perfect for off-grid systems and small scale energy needs
Modular Cartridge Design – Allows cell replacement without the need to replace the entire battery
